Huawei AirEngine 5762C-10-V2 is an indoor Wi-Fi 6 access point designed to provide high-performance wireless connectivity for indoor coverage scenarios such as SME offices, hospitals, cafés, and similar environments. Supporting simultaneous operation on the 2.4 GHz and 5 GHz frequency bands with 2×2 MIMO on each band, the AP delivers a peak data rate of up to 2.975 Gbit/s. Built to support high bandwidth and high user concurrency, it helps ensure a stable and efficient wireless experience even in busy network environments. Its compact design enables flexible deployment while helping organizations optimize space and protect infrastructure investment. By combining Wi-Fi 6 efficiency, strong wireless performance, and deployment flexibility, AirEngine 5762C-10-V2 offers a reliable solution for modern indoor connectivity requirements.
| Dimensions (D x H) | 180 mm x 35 mm |
| Power Input | PoE power supply: in compliance with IEEE 802.3af |
Maximum Power Consumption | 9.4 W |
Note: The actual maximum power consumption depends on local laws and regulations. | |
| Operating Temperature | 0°C to +40°C |
| Antenna Type | Built-in smart antennas |
| MIMO:Spatial Streams | 2.4 GHz: 2×2:2, 5 GHz: 2×2:2 |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax |
| Maximum Rate | 2.975 Gbps |
