Huawei AirEngine 5761-21 is a next-generation indoor Wi-Fi 6 access point designed to deliver high-performance wireless connectivity for environments that require strong bandwidth, stable coverage, and a high-quality user experience. Supporting six spatial streams and a maximum rate of up to 5.375 Gbit/s, the AP provides the speed and capacity needed for modern indoor network demands. Its built-in Smart Antennas allow Wi-Fi signals to actively follow users, helping maintain always-on coverage, improve signal quality, and provide a smoother connection experience across the deployment area. With its Wi-Fi 6 capabilities, intelligent antenna technology, and strong performance, AirEngine 5761-21 is well suited for small and midsize enterprise offices, educational institutions, retail outlets, and other indoor spaces that require reliable, efficient, and high-quality wireless access.
Featuring Multi-User Multiple-Input Multiple-Output (MU-MIMO) and Orthogonal Frequency Division Multiple Access (OFDMA) for efficient data transmission, plus 1024 Quadrature Amplitude Modulation (QAM), six spatial streams, and an air interface rate of up to 5.375 Gbit/s.
Dual-band co-planar Smart Antennas suppress interference automatically, double signal strength, and provide 20% wider coverage, realizing high-quality wireless coverage with zero blind spots.
Huawei’s cloud management platform simplifies the management of APs and services, reducing network Operations and Maintenance (O&M) costs.
| Dimensions (D x H) | 220 mm x 50 mm |
Power Input | DC: 12 V ±10% |
PoE power supply: In compliance with 802.3at. | |
Maximum Power Consumption | 17.9 W (excluding USB) |
Note: The actual maximum power consumption depends on local laws and regulations. | |
Maximum Number of Users | ≤ 1024 |
Note: The actual number of users varies according to the environment. | |
| Operating Temperature | –10°C to +50°C |
| Antenna Type | Built-in Smart Antennas |
| MIMO:Spatial Streams | 2.4 GHz: 2×2:2; 5 GHz: 4×4:4 |
| Radio Protocols | 802.11a/b/g/n/ac/ac wave2/ax |
| Maximum Rate | 5.375 Gbit/s |
