The Huawei AirEngine 8771-X1T is a next-generation Wi-Fi 7 (802.11be) access point designed for ultra-fast, high-density wireless environments. Ideal for cutting-edge applications, the Huawei AirEngine 8771-X1T is well-suited for scenarios like the metaverse, XR remote collaboration, XR telemedicine, and interactive XR-based education.
12T12R Antennas
Unique to Huawei, 12T12R antennas support up to 12 spatial streams, achieving throughput of up to 18.67 Gbps and enabling the AP to provide a fiber-like network experience for heavy-traffic services such as AR, VR, and XR remote collaboration.
Dynamic-Zoom Smart Antennas
Built-in dynamic-zoom smart antennas can flexibly work in omnidirectional or high-density coverage mode. The former mode promises wider coverage, while the latter mode maximizes performance and optimizes user experience in dense environments.
Tri-Band Radios
A tri-band radio design — 1 x 2.4 GHz, 1 x 5 GHz, and 1 x 6 GHz/5 GHz — supports 50% more concurrent users compared to dual-band APs.
| Dimensions (H x W x D) | 50 mm x 220 mm x 220 mm |
| Power Input | DC: 43.2 V to 57.6 V |
| PoE power supply: in compliance with 802.3bt (dual PoE inputs for hot backup) | |
| Maximum Number of Users | ≤ 1536 |
| Note: The actual number of users varies according to the environment. | |
| Operating Temperature | –10°C to +50°C |
| Antenna Type | Built-in dynamic-zoom smart antennas |
| MIMO:Spatial Streams | 2.4 GHz: 4×4:4, 5 GHz: 4×4:4, 6 GHz/5 GHz: 4×4:4 |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2/ax/be |
| Maximum Rate | 18.67 Gbps |
